Ginger Garlic Paste Packing Machine

Ginger Garlic Paste Packing Machine

250000 INR/Unit

Product Details:


Ginger Garlic Paste Packing Machine Price And Quantity

  • 1 Unit
  • 250000 INR/Unit

Product Description

We are involved in manufacturing and exporting a wide range of machinery for Paste Products like Ginger Garlic Paste Packing Machine. As the name implies, Offered machine is widely used in food processing industry for packing of garlic paste in pouches. Our technical experts make use of the finest quality components and contemporary techniques to efficiently manufacture this machine in conformity with set industry standards. Moreover, our clients can avail this Ginger Garlic Paste Packing Machine from us in different technical specifications at industry leading rates.


Feeding Head

Mechanical Piston filling system

Film Material

Laminated Film

Film Thickness

80 Microns

Film Width


Inner Core Dia of Film Roll


Machine Dimensions

Height-1500mm x Width-950mm x Length-1050mm

Net Weight

260 kg (Approx)

Outer Dia of the Film Roll


Packing Range

150 gram

Peak Power

3 kW

Pouch Counter


Pouch Style

Three Side sealing

Pouch Width

105 mm

Power Consumption

1.0kW / Hour

Power Requirement

1 Single Phase, 220 V 50Hz

Production Speed

50 Pouches per min

Sealer Heating System


Pouch Length

145 mm



  • This machine is equipped with single head and operates automatically
  • This machine can fill and seal the paste in hot temperature about 80-90 degree C
  • Have the versatility to provide fast changeover between many different packaging formats
  • Greater speed and versatility are the major benefits of this machine
  • The compact design of this machine improves the production capacity and consumes minimum power
  • Integrated temperature controller for energy conservation and film protection


Model Name: Cannon 100 4s PF



This machine is ideal for packaging of various types of viscous and non viscous liquids, paste, cream, tomato paste, sauce, jelly, ginger-garlic paste, fruit pulp, lubricant, adhesive, paints, dismembers, etc.


Technical Specifications

Feeding head

Mechanical piston filling system-Pneumatic piston filling system

Production speed

45 to 50 pouches per min

Packing range

10-100 ml-gm

Film Width

up to 210 mm

Film Thickness

60 to 80 microns

Film Material

Any heat sealable laminated film.

Sealer heating system

Continues only

Inner Core Dia. of Film Roll

70 mm

Outer Dia of the film roll

up to 350 mm

Pouch Style

3 or 4 side seal pillow pouch

Pouch width

up to 105 mm.

Pouch Length

up to 145 mm

Power Consumption

1.2 kW/Hour

Peak Power

3 kW

Air compressor

2 Hp. 1 Phase, 230 v,Ac 50 Hz (only for pneumatic machine)

Air consumption

4 CFM 20 C(only for pneumatic machine)

Compressed air pressure

6.5 kg-cm2(only for pneumatic machine)

Power requirement

Single Phase, 230 V, 50 Hz

Pouch Counter


Date printing Device


Machine Dimensions

Height 1500x Width 950x Length 1050mm

Net Weight

260 kgs (Approx).
